Zebra ZD888: ZPL guide
The Zebra ZD888 is a desktop printer with ZPL support. Below you will find the most important specifications for designing and printing labels as well as too…
Zebra ZD888: ZPL guide
The Zebra ZD888 is a desktop printer with ZPL support. Below you will find the most important specifications for designing and printing labels as well as tools to preview your ZPL.
Key specifications
| Model | Zebra ZD888 |
|---|---|
| --- | --- |
| Resolution | 203 DPI |
| Maximum print width | 104 mm (4.09") @ 203 DPI |
| Type | Desktop |
| Technology | Direct thermal and thermal transfer |
| Print speed | 6 ips / 152 mm/s or 4 ips / 102 mm/s |
| Memory | 128 MB Flash; 128 MB SDRAM |
| Firmware / languages | ZPL II; EPL 2; XML |
| Media width | 25.4-112 mm (1.00-4.4 in) |
| Maximum label length | 991 mm (39.0 in) |
| Connectivity | USB; factory options for Ethernet, Bluetooth 4.1, or Wi-Fi 802.11ac + Bluetooth 4.1 |
| Media sensors | Movable black mark sensor with limited center-left range; fixed off-center gap sensor |
Designing labels for the ZD888
Create your ZPL by adjusting the DPI to the printer and choosing a width within the specified maximum. Preview it in the viewer to avoid clipping or wasted material.
| DPI | Maximum width | ^PW value |
|---|---|---|
| --- | --- | --- |
| 203 DPI | 104 mm | ^PW831 |
^PW sets the printable width in dots. Use the value that matches the actual DPI of your printer.
^XA
^PW831
^LL1199
^FO40,40^A0N,38,38^FDZebra ZD888 - 203 DPI^FS
^FO40,100^GB751,2,2^FS
^FO40,130^A0N,28,28^FD104 mm / 831 dots^FS
^XZ
Official source
Technical data from Zebra ZD888 specification sheet.
- [View Zebra source](https://www.zebra.com/cn/zh/products/spec-sheets/printers/desktop/zd888.html)
FAQ
What resolution (DPI) does the ZD888 have?
Check the specification table: it lists the DPI available for this model.
Can I preview my ZPL for the ZD888 without printing?
Yes. Paste your code into the ZPL viewer and set the DPI of the ZD888 to see the label exactly as printed.
